MMO-HF

Download product group datasheet

Control cable for fixed installations indoors and outdoors. Not to be laid in soil nor directly in cast concrete. The conductor insulation must be protected against UV-radiation. Installations must be in accordance with national regulations and rules of installations. The cable is halogen-free and flame-retardant according to CPR-class Dca-s2,d2,a2.

Standards Applicable Parts of HD 627 S1:1996/A2:2005 Part 7 Section D-1
Reaction to fire Dca-s2,d2,a2
CPR - DoP 2017048_DOP.pdf
Conductor Circular solid copper, EN/IEC 60228 class 1
Insulation Halogen free polyethylene
Core Identification (all color combinations in the cable family) Black insulation, white numbers
Cable lay up Insulated cores twisted together
Separation sheath Halogen free filling compound
Oversheath UV-protected halogen-free polyolefin compound
Colour of the oversheath White

7x1,5

Electric number Size Packaging Voltage

7x1,5

Nominal diameter of complete cable mm 14
Nominal weight of cable kg/km 240
Conductor material Copper
Nominal diameter of conductor mm 1.36
Nominal cross-sectional area of conductor mm2 1.5
Nominal thickness of insulation mm 0.7
Number of wires 7
Min. bending radius
During handling and installation, cable mm 120
In final installation, cable mm 96
During handling and installation, cable cm 12
In final installation, cable cm 10
Max. pulling force
Pulling-eye kN 0.53
Resistance 20 °C Ω/km 12.1
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128411
Reka code 1145480
Nominal diameter of complete cable mm 14
Nominal weight of cable kg/km 240
Conductor material Copper
Nominal diameter of conductor mm 1.36
Nominal cross-sectional area of conductor mm2 1.5
Nominal thickness of insulation mm 0.7
Number of wires 7
Min. bending radius
During handling and installation, cable mm 120
In final installation, cable mm 96
During handling and installation, cable cm 12
In final installation, cable cm 10
Max. pulling force
Pulling-eye kN 0.53
Resistance 20 °C Ω/km 12.1
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128428
Reka code 1145480
Nominal diameter of complete cable mm 14
Nominal weight of cable kg/km 240
Conductor material Copper
Nominal diameter of conductor mm 1.36
Nominal cross-sectional area of conductor mm2 1.5
Nominal thickness of insulation mm 0.7
Number of wires 7
Min. bending radius
During handling and installation, cable mm 120
In final installation, cable mm 96
During handling and installation, cable cm 12
In final installation, cable cm 10
Max. pulling force
Pulling-eye kN 0.53
Resistance 20 °C Ω/km 12.1
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128404
Reka code 1145480

12x1,5

Electric number Size Packaging Voltage

12x1,5

Nominal diameter of complete cable mm 18
Nominal weight of cable kg/km 392
Conductor material Copper
Nominal diameter of conductor mm 1.36
Nominal cross-sectional area of conductor mm2 1.5
Nominal thickness of insulation mm 0.7
Number of wires 12
Min. bending radius
During handling and installation, cable mm 160
In final installation, cable mm 128
During handling and installation, cable cm 16
In final installation, cable cm 13
Max. pulling force
Pulling-eye kN 0.9
Resistance 20 °C Ω/km 12.1
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128435
Reka code 1145483

19x1,5

Electric number Size Packaging Voltage

19x1,5

Nominal diameter of complete cable mm 20
Nominal weight of cable kg/km 570
Conductor material Copper
Nominal diameter of conductor mm 1.36
Nominal cross-sectional area of conductor mm2 1.5
Nominal thickness of insulation mm 0.7
Number of wires 19
Min. bending radius
During handling and installation, cable mm 190
In final installation, cable mm 152
During handling and installation, cable cm 19
In final installation, cable cm 15
Max. pulling force
Pulling-eye kN 1.43
Resistance 20 °C Ω/km 12.1
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128442
Reka code 1145487

27x1,5

Electric number Size Packaging Voltage

27x1,5

Nominal diameter of complete cable mm 25
Nominal weight of cable kg/km 801
Conductor material Copper
Nominal diameter of conductor mm 1.36
Nominal cross-sectional area of conductor mm2 1.5
Nominal thickness of insulation mm 0.7
Number of wires 27
Min. bending radius
During handling and installation, cable mm 230
In final installation, cable mm 184
During handling and installation, cable cm 23
In final installation, cable cm 18
Max. pulling force
Pulling-eye kN 2.03
Resistance 20 °C Ω/km 12.1
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128459
Reka code 1145491

7x2,5

Electric number Size Packaging Voltage

7x2,5

Nominal diameter of complete cable mm 16
Nominal weight of cable kg/km 358
Conductor material Copper
Nominal diameter of conductor mm 1.74
Nominal cross-sectional area of conductor mm2 2.5
Nominal thickness of insulation mm 0.8
Number of wires 7
Min. bending radius
During handling and installation, cable mm 150
In final installation, cable mm 120
During handling and installation, cable cm 15
In final installation, cable cm 12
Max. pulling force
Pulling-eye kN 0.88
Resistance 20 °C Ω/km 7.41
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128527
Reka code 1145505

12x2,5

Electric number Size Packaging Voltage

12x2,5

Nominal diameter of complete cable mm 20
Nominal weight of cable kg/km 550
Conductor material Copper
Nominal diameter of conductor mm 1.74
Nominal cross-sectional area of conductor mm2 2.5
Nominal thickness of insulation mm 0.8
Number of wires 12
Min. bending radius
During handling and installation, cable mm 180
In final installation, cable mm 144
During handling and installation, cable cm 18
In final installation, cable cm 14
Max. pulling force
Pulling-eye kN 1.5
Resistance 20 °C Ω/km 7.41
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128534
Reka code 1145508

19x2,5

Electric number Size Packaging Voltage

19x2,5

Nominal diameter of complete cable mm 25
Nominal weight of cable kg/km 823
Conductor material Copper
Nominal diameter of conductor mm 1.75
Nominal cross-sectional area of conductor mm2 2.5
Nominal thickness of insulation mm 0.8
Number of wires 19
Min. bending radius
During handling and installation, cable mm 230
In final installation, cable mm 184
During handling and installation, cable cm 23
In final installation, cable cm 18
Max. pulling force
Pulling-eye kN 2.38
Resistance 20 °C Ω/km 7.41
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128541
Reka code 1145512

27x2,5

Electric number Size Packaging Voltage

27x2,5

Nominal diameter of complete cable mm 29
Nominal weight of cable kg/km 1174
Conductor material Copper
Nominal diameter of conductor mm 1.75
Nominal cross-sectional area of conductor mm2 2.5
Nominal thickness of insulation mm 0.8
Number of wires 27
Min. bending radius
During handling and installation, cable mm 270
In final installation, cable mm 216
During handling and installation, cable cm 27
In final installation, cable cm 22
Max. pulling force
Pulling-eye kN 3.38
Resistance 20 °C Ω/km 7.41
Minimum cable temperature during transport °C -40
Minimum cable temperature during handling and installation °C -15
Minimum cable temperature during operation °C -40
Maximum conductor temperature in normal operation °C 70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C 160
EAN code 6410004128558
Reka code 1145516
