KJAAM-ARM
Download product group datasheet
Instrumentation cable for fixed installations indoors and outdoors. May be buried directly in soil. Cable gives good protection against rodents and other mechanical stress. EMC shielded cable gives an excellent protection against electromagnetic disturbancies. Installations must be in accordance with national regulations and rules of installations. The cable is flame-retardant according to CPR-class Eca.
| Standards | EN 50288-7 |
|---|---|
| Reaction to fire | Eca |
| CPR - DoP | 2017051_DOP.pdf |
| Conductor | Circular stranded tinned copper, EN/IEC 60228 class 2 |
| Insulation | Halogen free polyethylene |
| Core Identification (all color combinations in the cable family) | Blue, red |
| Individual shield | Aluminium tape and earthing conductor |
| Cable lay up | Insulated wires twisted in pairs. Colors in pairs blue and red. Pairs marked with a numbers. |
| Separation sheath | Inner sheath, Halogen free compound |
| Overall shield | Two aluminium tapes and earthing conductor (tinned copper, between the tapes) |
| Armour | Galvanized steel |
| Oversheath | UV-protected halogen-free polyolefin compound |
| Colour of the oversheath | Black |
4x(2+1)x0,5 BK
Electric number
Size
Packaging
Voltage
4x(2+1)x0,5 BK
Nominal diameter of complete cable mm
14
Nominal weight of cable kg/km
291
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
8
Min. bending radius
During handling and installation, cable mm
203
In final installation, cable mm
136
During handling and installation, cable cm
20
In final installation, cable cm
14
Max. pulling force
Pulling-eye kN
0.2
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654547
Reka code
1147614
Nominal diameter of complete cable mm
14
Nominal weight of cable kg/km
291
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
8
Min. bending radius
During handling and installation, cable mm
203
In final installation, cable mm
136
During handling and installation, cable cm
20
In final installation, cable cm
14
Max. pulling force
Pulling-eye kN
0.2
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654172
Reka code
1147614
8x(2+1)x0,5 BK
Electric number
Size
Packaging
Voltage
8x(2+1)x0,5 BK
Nominal diameter of complete cable mm
19
Nominal weight of cable kg/km
478
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
16
Min. bending radius
During handling and installation, cable mm
280
In final installation, cable mm
187
During handling and installation, cable cm
28
In final installation, cable cm
19
Max. pulling force
Pulling-eye kN
0.4
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654585
Reka code
1147618
Nominal diameter of complete cable mm
19
Nominal weight of cable kg/km
478
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
16
Min. bending radius
During handling and installation, cable mm
280
In final installation, cable mm
187
During handling and installation, cable cm
28
In final installation, cable cm
19
Max. pulling force
Pulling-eye kN
0.4
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654189
Reka code
1147618
12x(2+1)x0,5 BK
Electric number
Size
Packaging
Voltage
12x(2+1)x0,5 BK
Nominal diameter of complete cable mm
21
Nominal weight of cable kg/km
592
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
24
Min. bending radius
During handling and installation, cable mm
310
In final installation, cable mm
207
During handling and installation, cable cm
31
In final installation, cable cm
21
Max. pulling force
Pulling-eye kN
0.6
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654622
Reka code
1147622
Nominal diameter of complete cable mm
21
Nominal weight of cable kg/km
592
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
24
Min. bending radius
During handling and installation, cable mm
310
In final installation, cable mm
207
During handling and installation, cable cm
31
In final installation, cable cm
21
Max. pulling force
Pulling-eye kN
0.6
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654196
Reka code
1147622
24x(2+1)x0,5 BK
Electric number
Size
Packaging
Voltage
24x(2+1)x0,5 BK
Nominal diameter of complete cable mm
28
Nominal weight of cable kg/km
1005
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
48
Min. bending radius
During handling and installation, cable mm
425
In final installation, cable mm
283
During handling and installation, cable cm
42
In final installation, cable cm
28
Max. pulling force
Pulling-eye kN
1.2
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654202
Reka code
1147634
Nominal diameter of complete cable mm
28
Nominal weight of cable kg/km
1005
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
48
Min. bending radius
During handling and installation, cable mm
425
In final installation, cable mm
283
During handling and installation, cable cm
42
In final installation, cable cm
28
Max. pulling force
Pulling-eye kN
1.2
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654745
Reka code
1147634
48x(2+1)x0,5 BK
Electric number
Size
Packaging
Voltage
48x(2+1)x0,5 BK
Nominal diameter of complete cable mm
38
Nominal weight of cable kg/km
1703
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
96
Min. bending radius
During handling and installation, cable mm
566
In final installation, cable mm
377
During handling and installation, cable cm
57
In final installation, cable cm
38
Max. pulling force
Pulling-eye kN
2.4
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654219
Reka code
1147650
Nominal diameter of complete cable mm
38
Nominal weight of cable kg/km
1703
Conductor material
Copper
Nominal diameter of conductor mm
0.9
Nominal cross-sectional area of conductor mm2
0.5
Nominal thickness of insulation mm
0.4
Number of wires
96
Min. bending radius
During handling and installation, cable mm
566
In final installation, cable mm
377
During handling and installation, cable cm
57
In final installation, cable cm
38
Max. pulling force
Pulling-eye kN
2.4
Resistance 20 °C Ω/km
37,4
Minimum cable temperature during transport °C
-40
Minimum cable temperature during handling and installation °C
-10
Minimum cable temperature during operation °C
-40
Maximum conductor temperature in normal operation °C
70
Maximum conductor temperature during short circuit (not exceeding 5 sec.) °C
160
EAN code
6410002654981
Reka code
1147650
